Shaanxi Elade New Material Technology Co.,Ltd is one of the leading China magnesium anode manufacturers, and with professional factory we are able to provide you cheap magnesium anode, Mg anode with good quality. Welcome to wholesale products from us.
Specifications
◆carry out standard ASTM-98 ; high potential anode
◆fine performance
◆factory direct
High potential magnesium anode in conform to the standard ASTM-98is made from high purity magnesium with high quality. The anode adopting special technique holds splendid electrochemistry performance. In the process of cathode protection, anode consumption is stable; therefore, it has longer life time. In the actual used process, the actual measurement working potential is between-1.8v and 1.85v; therefore, it can provide the most effective protection for structures. It is suggested to use potential magnesium anode in the soil whose resistance is over 8000ohm.cm.
Electrochemical Performance
Designation | Opened-circuit potential -V, Cu/CuSO4 | Closed-circuit potential -V, Cu/CuSO4 | Actual capacity (A. h/kg) | Current efficiency(%) |
MGAZ63B | 1.57~1.67 | 1.52~1.57 | ≥1210 | ≥55 |
MGAZ31B | 1.57~1.67 | 1.47~1.57 | ≥1210 | ≥55 |
MGAM1C | 1.77~1.82 | 1.64~1.69 | ≥1100 | ≥50 |
The chemical component of magnesium alloy anode
Designation | Alloying Element | Impurity element, not more than | |||||||
Al | Zn | Mn | Mg | Fe | Cu | Ni | Si | Ca | |
MGAZ63B | 5.3-6.7 | 2.5-3.5 | 0.15-0.60 | Balance | 0.003 | 0.01 | 0.001 | 0.08 | -- |
MGAZ31B | 2.5-3.5 | 0.60-1.4 | 0.20-1.0 | Balance | 0.003 | 0.01 | 0.001 | 0.08 | 0.04 |
MGM1C | ≤0.01 | -- | 0.50-1.3 | Balance | 0.01 | 0.01 | 0.001 | 0.05 | -- |
MG | ≤0.02 | ≤0.03 | ≤0.01 | ≥99.9 | 0.005 | 0.004 | 0.001 | 0.01 | -- |
